Knife Grinder

Knife Grinder

  • Min.Order Quantity: 1 Set/Sets
  • Supply Ability: 10 Set/Sets per Month
  • Port: china ports
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  0
  • Place of Origin:  china
  • Brand Name:  hanvy
  • Model Number:  YM3000B
  • Weight: 0.000 kg

Knife grinder is aimed at turning tool, bit, cutter, carving knife, computer engraving machine, engraving machine, machining center, CNC, carving machine, dividing machine, marking machine and other metal grinding equipments.

The machine is widely used in plywood and veneer production industry, used to sharpening the knife on Veneer Peeling Machine and Veneer Clipper, Veneer slicer, to guarantee the machine in good and continuous working condition.

For the knife grinder, there are more selections for user to choose, like the common model with electromagnetic chuck, precision model with linear guide and inventer and all screw.

  • Size:  0
  • Place of Origin:  china
  • Brand Name:  hanvy
  • Model Number:  YM3000B
  • Weight: 0.000 kg

MD-1500C

MD-2000C

MD-2500C

MD-3000C

Grinding length

1500mm

2000mm

2500mm

3000mm

Grinding head rotation speed

1400r/min

1400r/min

1400r/min

1400r/min

Worktable size

180x1500mm

180x2000mm

180x2500mm

180x3000mm

Grinding head motor power

4/5.5/7.5/11kw

4/5.5/7.5/11kw

4/5.5/7.5/11kw

4/5.5/7.5/11kw

Grinding head travel speed

0-16m/min

0-16m/min

0-16m/min

0-16m/min

Travel motor power

1.1kw

1.1kw

1.1kw

1.1kw

Grinding wheel dimension

Φ200x110x32mm

Φ200x110x32mm

Φ200x110x32mm

Φ200x110x32mm

Overall dimension

3500x1100x1300mm

4000x1100x1300mm

4500x1100x1300mm

5000x1100x1300mm

weight

2100kg

2400kg

2700kg

3000kg

Worktable angle adjustment

±45°

±45°

±45°

±45°
